El TSW010 ofrece la forma más asequible de ampliar la conectividad de red a múltiples dispositivos Ethernet. Cinco puertos Ethernet de 10/100 Mbps garantizan una conectividad estable y fiable, suficiente para la mayoría de las aplicaciones industriales en las que no se requiere un alto rendimiento.
Características
ETHERNET
- ETH5 x ETH port, 10/100 Mbps, supports auto MDI/MDIX crossover
- IEEE 802.3 series standards802.3i, 802.3u, 802.3x, 802.3az
PERFORMANCE SPECIFICATIONS
- Bandwidth (Non-blocking)1 Gbps
- MAC address table size2K entries
- Jumbo frame support2048 bytes
POWER
- Connector2-pin industrial DC power socket
- Input voltage range9 – 30 VDC
- PoE (passive)Possibility to power up through ETH1 ports, not compatible with IEEE802.3af, 802.3at and 802.3bt standards, Mode B, 9 – 30 VDC
- Power consumption Idle: 0.3 W / Max: 0.9 W
PHYSICAL INTERFACES
- Ethernet5 x RJ45 ports, 10/100 Mbps
- Status LEDs1 x Power LED, 10 x ETH status LEDs
- Power1 x 2-pin industrial DC power socket
PHYSICAL SPECIFICATION
- Casing materialAluminium housing
- Dimensions (W x H x D)113.1 x 27.4 x 80.5 mm
- Weight146.5 g
- Mounting optionsIntegrated DIN rail bracket, wall mount, flat surface (additional kit needed)
OPERATING ENVIRONMENT
- Operating temperature-40 °C to 75 °C
- Operating humidity10% to 90% non-condensing
- Ingress Protection RatingIP30
REGULATORY & TYPE APPROVALS
- RegulatoryCE, REACH, RoHS, WEEE, UKCA, FCC, IC, CB, RCM
SAFETY
- StandardsEN IEC 62368-1:2020+A11:2020
